A UNIVERSAL SOFTWARE PLATFORM

PolyWorks|Inspector™ is a universal 3D dimensional analysis and quality control software solution to control tool or part dimensions, diagnose and prevent manufacturing and assembly issues, guide assembly building through real-time measurements, and oversee the quality of assembled products by using portable metrology devices and CNC CMMs.

  • IDENTIFY DEFORMATIONS IN EARLY MANUFACTURING PROCESSES

  • FULL INSPECTION OF FIRST ASSEMBLED PRODUCTS

  • VERIFY THE COMPLIANCE OF FINAL MANUFACTURED AND ASSEMBLED PRODUCTS

Not Ready to Buy? Learn More About Our 3D Scanning Services

Request a Quote

Name(Required)
Address(Required)
This field is for validation purposes and should be left unchanged.
3D Scan Data from InnovMetric PolyWorks | Inspector

Achieving Quality Excellence Together

Explore the entire PolyWorks Solutions offered by Exact Metrology

Achieving Quality Excellence Together

Explore the entire PolyWorks Solutions offered by Exact Metrology

COMPUTER REQUIREMENTS

Minimum Computer Requirements*

  • CPU: Dual-core
  • RAM: 4 GB
  • Graphics cards: Hardware-accelerated, professional OpenGL graphics card (NVIDIA certified cards and drivers) equipped with 1 GB of memory
  • Operating system: 64-bit Windows 10, Professional Edition
  • Input device: Two-button mouse with wheel

*These requirements are adequate if you are planning to use single-point probing devices and your CAD model file sizes are smaller than 50 MB.
Recommended Computer Requirements**

  • CPU: Quad-core CPU
  • RAM: 32 GB
  • Graphics card: NVIDIA RTX / Quadro series graphics card equipped with 2 GB of memory (NVIDIA certified cards and drivers)
  • Operating system: 64-bit Windows 10, Professional Edition
  • Input device: Two-button mouse with wheel

**This configuration covers a broad range of applications by offering the performance required when importing larger CAD models or laser scanning large parts with high resolution. If you have doubts about the best system configuration for your type of application, contact our technical support team.

SINGLE POINT MEASURING DEVICE PLUG-INS

  • Arms: Faro, Hexagon/Romer, Nikon, Mitutoyo, CimCore, Kreon, RPS Metrology, Tomelleri-SpaceArms, TTS Vectoron
  • Handheld, optically tracked devices: Aicon, Creaform, Geodetic, Keyence, Metronor, Nikon, NDI, Zeiss
  • Laser trackers: API, Faro, Leica
  • Manual CMMs: I++, Deva, MZ1060, Renishaw, Samsoft, Wenzel
  • CNC CMM controllers, through direct drivers: Brown & Sharpe, Coord3, DEA, Leitz, LK, Mitutoyo, Pantec, Sb-Elektronik, Wenzel
  • CNC CMM controllers, through Zeiss CMM-OS: Zeiss
  • CNC CMM controllers, through I++: All brands
  • Theodolites: Leica TDRA6000

POINT CLOUD DIGITIZING DEVICE PLUG-INS

  • Line scanners: API, Faro, Hexagon, Kreon, Laser Design, Leica, Mitutoyo, NDI, Nikon, Perceptron, TTS Vectoron, Zeiss
  • Planar grid scanners: Faro, Leica, Konica Minolta
  • Spherical grid scanners: Surphaser
  • Polygonal mesh scanners: Creaform, Hexagon
  • Direct point scanners: Leica, Nikon
  • CNC CMM line scanners, through direct drivers: Kreon, Nikon
  • CNC CMM line scanners, through I++: Hexagon, Zeiss

POINT CLOUD FILE FORMATS

38 formats describing planar grids/meshes, line scans, spherical grids, and unorganized point clouds.

MEASUREMENT COLLECTION DEVICE PLUG-INS

  • Receivers: MicroRidge (MobileCollect, GageWay), Mitutoyo U-Wave
  • Devices: All devices compatible with the above receivers and all those that allow keyboard input simulation.

CAD FILE FORMATS

  • CATIA V6/V5/V4
  • NX (UG)
  • Creo (Pro/E)
  • Inventor
  • SolidWorks
  • ACIS
  • IGES
  • JT
  • Parasolid
  • STEP
  • VDA-FS

LANGUAGES

  • Chinese (Simplified and Traditional)
  • Czech
  • English
  • French
  • German
  • Hungarian
  • Italian
  • Japanese
  • Korean
  • Polish
  • Portuguese
  • Russian
  • Spanish
